Crimson Trace CTS-25 Manual: A Comprehensive Guide
Welcome! This manual provides detailed instructions for the CTS-25 compact red dot sight. Explore setup‚ operation‚ maintenance‚ and troubleshooting for optimal performance.
Discover its features!
The Crimson Trace CTS-25 is a highly versatile and compact red dot sight designed to enhance accuracy and speed in a variety of shooting applications. Engineered for both professional and recreational shooters‚ the CTS-25 boasts a low-profile design‚ making it ideal for mounting on pistols‚ rifles‚ and shotguns without obstructing a clear sight picture.
This sight features a crisp and clear 4 MOA (Minute of Angle) dot‚ providing precise aiming at various distances. Its robust construction ensures durability and reliability‚ even in demanding environments. The CTS-25 is equipped with seven adjustable brightness levels‚ allowing users to customize the dot’s intensity to match ambient lighting conditions.
Furthermore‚ the included removable riser enables co-witnessing with iron sights‚ offering a seamless transition between aiming systems. The sight’s intuitive controls and straightforward operation make it user-friendly for shooters of all experience levels. This manual will guide you through every aspect of the CTS-25‚ from initial setup and zeroing to maintenance and troubleshooting‚ ensuring you maximize its potential.
Unboxing and Components
Upon receiving your Crimson Trace CTS-25 Compact Red Dot Sight‚ carefully inspect the packaging for any signs of damage during transit. Once confirmed secure‚ open the box and verify the presence of all included components. Your CTS-25 package should contain the following:
- CTS-25 Red Dot Sight: The primary unit‚ featuring the 4 MOA red dot reticle and adjustable brightness controls.
- Removable Riser: Allows for co-witnessing with standard height iron sights‚ enhancing versatility.
- Lens Cover: Protects the objective lens from scratches and damage during storage and transport.
- CR2032 Battery: Powers the red dot illumination.
- Hex Key: Used for mounting and zeroing adjustments.
- User Manual: This document‚ providing comprehensive instructions for operation and maintenance.
If any components are missing or appear damaged‚ immediately contact Crimson Trace customer support. Retain the original packaging for potential returns or warranty claims. Familiarize yourself with each component before proceeding to the mounting stage. Proper inventory ensures a smooth setup process.
Mounting the CTS-25
Mounting the CTS-25 requires a compatible mounting platform‚ typically a Picatinny or Weaver rail. Ensure the rail is securely attached to your firearm. Begin by loosening the screws on the CTS-25’s mounting base‚ but do not remove them completely. Position the sight onto the rail‚ aligning it to your desired location.
Carefully tighten the screws‚ alternating between them to ensure even pressure and prevent misalignment. Avoid over-tightening‚ as this could damage the sight or the rail. Once securely mounted‚ verify the sight’s stability by gently attempting to move it. It should remain firmly in place.
If utilizing the included riser‚ install it before mounting the sight to the rail. The riser provides additional height for co-witnessing with iron sights. Double-check all screws after initial use and periodically thereafter to maintain a secure zero. Proper mounting is crucial for accuracy and reliable performance.
Battery Installation and Replacement
The CTS-25 operates on a CR2032 button cell battery. To install or replace the battery‚ locate the battery compartment on the side of the sight. Use a small‚ flathead screwdriver or the included tool to gently open the battery compartment cover.
Remove the old battery‚ noting its polarity (+ side up). Insert the new CR2032 battery‚ ensuring the + side faces upwards as indicated inside the compartment. Carefully close the battery compartment cover‚ making sure it clicks securely into place. A loose cover can cause the sight to malfunction.
Low battery indication is signaled by a flickering reticle. Replace the battery promptly when this occurs to avoid interruption during use. Always dispose of used batteries responsibly‚ following local regulations. Battery life varies depending on brightness settings and usage. Keep a spare battery readily available.
Powering On/Off and Brightness Adjustment
The CTS-25 is activated by pressing the power button located on the side of the sight. A single press turns the sight on‚ displaying the 4 MOA red dot reticle. To power off‚ press and hold the same button for approximately three seconds until the reticle disappears. This prevents accidental activation during storage.
Brightness adjustment is also controlled via the same power button. Short presses of the power button while the sight is on cycle through seven different brightness levels. These levels accommodate various lighting conditions‚ from bright daylight to low-light environments.
The sight automatically remembers the last selected brightness level‚ providing convenience for repeated use. For maximum battery life‚ use a lower brightness setting when appropriate. Note that higher brightness levels consume more power. A quick double-press will return the sight to the previously used brightness setting.
Understanding the 4 MOA Dot
The Crimson Trace CTS-25 utilizes a 4 Minute of Angle (MOA) red dot reticle. This means that at 100 yards‚ the dot will cover approximately 4 inches. This size is considered ideal for quick target acquisition and general shooting applications‚ offering a balance between precision and visibility.
The 4 MOA dot is designed to be unobtrusive‚ allowing for a clear view of the target without excessive visual clutter. It’s small enough for accurate shots at moderate distances‚ yet large enough to be easily seen in various lighting conditions. The red color provides excellent contrast against most backgrounds.
Unlike thicker dots‚ a 4 MOA dot minimizes target obscuration‚ particularly at longer ranges. This is crucial for maintaining accuracy and confidence. The clarity of the dot is enhanced by the high-quality lens used in the CTS-25‚ ensuring a crisp and defined aiming point. Experiment with different brightness settings to find the optimal dot visibility for your specific shooting environment.
Zeroing the CTS-25 Sight
Achieving accurate shots requires proper zeroing of your CTS-25. Begin by mounting the sight securely to your firearm. At a known distance – typically 25 or 50 yards – fire a grouping of shots at a target. Observe where the impacts land relative to your intended point of aim.
The CTS-25 features adjustable windage and elevation screws. Use a suitable tool to make small‚ incremental adjustments. Remember the direction of adjustment: ‘Up’ raises the point of impact‚ ‘Down’ lowers it‚ ‘Right’ moves it right‚ and ‘Left’ moves it left. After each adjustment‚ fire another grouping to assess the change.
Continue this process of shooting‚ observing‚ and adjusting until your shots consistently impact at your desired point of aim. Patience is key! It’s recommended to zero the sight from a stable shooting position‚ such as a benchrest‚ for maximum accuracy. Once zeroed‚ it’s wise to confirm the zero at different distances to ensure consistent performance.
Co-Witnessing with Iron Sights
Co-witnessing allows you to align the red dot sight with your firearm’s iron sights‚ providing a backup aiming solution if the electronic sight fails. The CTS-25 is designed to work with standard height iron sights‚ offering a lower 1/3 co-witness.
To achieve co-witnessing‚ ensure your iron sights are properly zeroed first. Then‚ mount the CTS-25. Ideally‚ the red dot’s 4 MOA dot should be centered within the rear sight notch when looking through both aiming systems. If the dot isn’t aligned‚ you may need to adjust your iron sights or utilize the included removable riser.
The riser elevates the CTS-25‚ potentially enabling a full co-witness with taller iron sights. Experiment with the riser to find the optimal alignment for your setup. Consistent co-witnessing ensures a seamless transition between aiming methods. Regularly verify the alignment‚ especially after removing or reattaching the sight. This provides a reliable backup for any situation.
Using the Removable Riser
The CTS-25 includes a removable riser‚ offering increased mounting height flexibility. This is particularly useful for achieving a proper cheek weld or for co-witnessing with higher-profile iron sights. The riser easily attaches to the sight’s base using the provided screws.
To install the riser‚ first‚ loosen the screws on the sight’s base. Carefully position the riser onto the base‚ ensuring it’s properly aligned. Tighten the screws securely‚ but avoid over-tightening‚ which could damage the sight or riser. Once installed‚ the riser elevates the optic‚ changing the sight picture.
Experiment with and without the riser to determine which configuration best suits your shooting style and firearm setup. The riser can also improve ergonomics for certain shooters. Remember to re-zero the sight after installing or removing the riser‚ as the point of impact will shift. Proper installation and zeroing are crucial for accuracy.
Sight Maintenance and Cleaning
Maintaining your CTS-25 ensures long-lasting performance and accuracy. Regular cleaning is essential‚ especially after exposure to harsh environments. Always power off the sight before any maintenance. Use a soft‚ dry cloth to wipe away dust‚ dirt‚ and fingerprints from the exterior housing and lenses.
For stubborn debris‚ slightly dampen the cloth with lens cleaning solution specifically designed for optics. Avoid abrasive cleaners or solvents‚ as these can damage the coatings. Gently clean the lenses in a circular motion. Inspect the battery compartment for any corrosion and clean if necessary.
Periodically check the mounting screws to ensure they remain tight. Store the sight in a protective case when not in use. Avoid exposing the sight to extreme temperatures or prolonged direct sunlight. Proper care will preserve the integrity and functionality of your Crimson Trace optic‚ guaranteeing years of reliable service.
Troubleshooting Common Issues
If your CTS-25 isn’t functioning correctly‚ begin with basic checks. If the dot is dim or absent‚ first verify the battery is fresh and correctly installed. Ensure the brightness setting isn’t set to its lowest level‚ or inadvertently on a setting too low for ambient light.
If the sight won’t power on‚ double-check battery polarity. If zeroing seems impossible‚ confirm the sight is securely mounted and that all screws are tightened. Ensure proper eye relief and a stable shooting platform; If parallax shift is observed‚ re-zero the sight following the instructions in the manual.
For intermittent issues‚ try resetting the sight by removing and reinstalling the battery. If the dot appears blurry‚ clean the lenses thoroughly. If problems persist‚ consult the Crimson Trace website or contact their customer support for further assistance. Avoid disassembling the sight yourself‚ as this will void the warranty.
Safety Precautions
Important Safety Information: Always treat every firearm as if it is loaded. Never point a firearm at anything you are not intending to shoot. Keep your finger off the trigger until you are ready to fire. Be certain of your target and what is beyond it.
When installing or removing the CTS-25‚ ensure the firearm is unloaded. Avoid looking directly into the red dot‚ especially at high brightness settings‚ as it may cause temporary visual impairment. Store the sight in a safe place‚ away from children and unauthorized individuals.
Regularly inspect the sight for any damage or loose components. If damage is detected‚ discontinue use and contact Crimson Trace for repair or replacement. Never attempt to modify or disassemble the sight beyond what is described in this manual. Always follow all local‚ state‚ and federal laws regarding firearm ownership and use. Prioritize safe handling practices at all times.
Technical Specifications
CTS-25 Overview: The Crimson Trace CTS-25 is a compact red dot sight designed for pistols and other firearms. It features a 4 MOA dot size‚ providing precise aiming for various shooting applications. The sight boasts 7 adjustable brightness levels‚ ensuring visibility in diverse lighting conditions.
Dimensions & Weight: The CTS-25 measures approximately 1.6″ x 1.1″ x 1.0″ and weighs just 1.4 ounces (without battery). Optical Characteristics: It offers unlimited eye relief and a wide field of view. The lens is fully multi-coated for enhanced clarity and light transmission.
Power & Battery: The sight operates on a single CR2032 battery‚ providing an extended runtime of up to 80 hours on medium brightness settings. Construction: Constructed with a durable aluminum alloy‚ the CTS-25 is built to withstand recoil and harsh environments. It’s water resistant and shockproof‚ ensuring reliable performance.
Warranty Information
Crimson Trace Limited Lifetime Warranty: Crimson Trace warrants its CTS-25 sight to be free from defects in materials and workmanship for the lifetime of the original purchaser. This warranty is non-transferable and applies only to normal use.
Coverage Details: The warranty covers repairs or replacement of the product‚ at Crimson Trace’s discretion‚ should it prove defective. This does not cover damage resulting from misuse‚ abuse‚ improper installation‚ unauthorized modifications‚ or normal wear and tear.
Warranty Process: To initiate a warranty claim‚ contact Crimson Trace customer support (details in the ‘Support and Resources’ section). You will need to provide proof of purchase and a detailed description of the issue. Crimson Trace will issue a Return Merchandise Authorization (RMA) number.
Exclusions: Batteries‚ shipping costs to and from Crimson Trace‚ and any consequential damages are not covered under this warranty. Crimson Trace reserves the right to modify the terms of this warranty at any time.
Crimson Trace Support and Resources
Customer Support: For immediate assistance with your CTS-25‚ contact Crimson Trace’s dedicated support team. You can reach them via phone at 1-800-444-2404 during business hours (Monday-Friday‚ 8 AM to 5 PM PST). Alternatively‚ email support is available at support@crimsontrace.com. Expect a response within 24-48 hours.
Online Resources: The official Crimson Trace website (www.crimsontrace.com) is a valuable resource. Explore the ‘Support’ section for frequently asked questions (FAQs)‚ downloadable manuals (including this one!)‚ and helpful videos demonstrating setup and troubleshooting.
Community Forums: Engage with fellow CTS-25 users and share experiences on popular online firearm forums. These communities often provide valuable insights and solutions to common issues. Search for “Crimson Trace CTS-25” on platforms like AR15.com or Reddit’s r/optic.
Social Media: Stay updated on Crimson Trace’s latest news‚ product releases‚ and support announcements by following them on social media platforms like Facebook‚ Instagram‚ and YouTube. Links are available on their website.
